Apalachicola Bay Dredging Plan, 1890

Apalachicola Bay : plan showing channel dredged Nov. 1889-May 1890 (contract of Alabama Dredging & Jetty Co.)


Apalachicola Bay Dredging Plan, 1890

Map Number

fmc0118

Source

State Library of Florida, Florida Map Collection, GEOGRAPHIC AREA APALACHICOLA 0001

Date

1890

Creator

United States. Army. Corps of Engineers.

Additional Creators

Robinson, Thomas.

Price, Philip M.

A. Hoen & Co.

Publisher

Montgomery, Ala. : The Corps, [1890] A. Hoen & Co.

Physical Description

1 map ; 39 x 24 cm., on sheet 43 x 26 cm.

Scale

Scale [ca. 1:24,000]. 2000 ft. to 1 in.

General Notes

Depths shown by bathymetric soundings.

Soundings ... by ... Thos. Robinson, May 1890.

Made under the direction of Capt. Philip M. Price, Corps of Engineers, U.S.A.

To accompany annual report for 1890.

Includes: Enlarged plan of cut. [Scale ca. 1:2,400].

Inset: Plan of benches for mean low tide level.

Eng 90.
